- Large Capacity: The fuel tank of this outboard engine has a capacity of 1.8 liters, which enables it to work for you continuously for more than an hour. An excellent working hours to meet the needs of long-distance travel and work.
- Fuel-saving: This outboard engine adopts a high-precision intake and exhaust system to improve fuel conversion rate. The outboard engine is four-stroke, which saves about 30% more fuel than a two-stroke.
- Flexible Steering: This outboard engine has a 180-degree steering function, allowing you to easily control the steering of your boat.
- Powerful: With a displacement of 196cc and a speed of 3600r/min, this outboard engine is able to provide strong power.
- Easy to Operate: This outboard engine features a step-less variable speed mode, allowing you to control the speed easily. This outboard engine also has forward, neutral, and reverse gear settings, which can be adapted to different work requirements.
- Application The outboard engine is suitable for all kinds of small boats of 2.7~8 meters, such as rubber boats, wooden boats, fishing boats, etc. It can be widely used in water sports, water tourism, fishery production, and other fields.
How to Use
1. Add enough gasoline and the right amount of engine oil. The amount of oil is based on the scale mark.
2. Turn on the flameout switch and snap the black buckle of the emergency flameout cable on.
3. Close the damper (the damper is closed before cold air starts, and the damper is open before the hot engine starts)
4. Throttle handle adds a little throttle.
5. Pull the starter puller to turn on the engine.
6. Open the damper to the maximum, start the rear damper and keep it open the whole time. (number 1 is off, number 4 is on)
Specification
Material: Aluminum, Steel Pipe, Plastic
Speed: 8-15 km/h
Fuel Tank Capacity: 1.8L/0.47gal
Displacement: 196cc
Rotational Speed: 3600r/min
Motor: Four-stroke
Power: 7.5hp
Product Size: 118*38cm/46.45*14.96in
Handle Length: 84cm/33.07in
Operating Rod Length: 80cm/31.51in
Package Size: 128*54*40.5cm/50.39*21.25*15.94in
Applicable Boat Length: 2.7-8m/8.85-26.24ft
Net Weight: 33kg/72.75lbs
Gross Weight: 34kg/74.95lbs
Package Included
1*Outboard Engine
1*Funnel
All Accessories for Installation
Notes
1. The driving speed is about 8~15km/h, and the driving distance is different depending on the type of boat and the current condition of the load.
2. The four-stroke fuel is 92#, and the engine oil is added to the internal tank separately.
3. The outboard engine was factory tested for one hour before leaving the factory. It is normal to have a bit of wear and tear.
4. Please allow the slight color difference caused by the shooting light and 1-3cm error due to manual measurement. Please make sure you do not mind before you order.
